- Quarter turn SCOTCH YOKE Mechanism
- Single Acting
- Symmetric or canted yoke design
- Pneumatic power supply (up to 12 BARG)
- Output Torque Up to 800.000 Nm
- Standard temperature range -20°C +85°C
- Low temperature version -60°C + 85°C
- PED 2014/68/UE Compliant
- ATEX 2014/34/UE Compliant
- IP67M, NEMA 4, 4x & 6 as minimum
- SIL3 Certified IEC 61508
- Corrosion resistant cylinder
- Manual Override available
- Protected travel stops are standard
- Modular concept
- Actuator in carbon steel – NO Aluminum NO Cast Iron
- Pressure retaining components and power springs 3.1 Certified according to EN10204 3.1
